Select this model digital controller for powering Adaptive Scissor Lifts into two positions, up and down. It receives its signals from adjustable contact switches mounted to the scissor lift.
The controller mounts either directly to the scissor lift’s chassis, or to nearby structure, up to 6 feet away from the chassis. A 6 foot-long umbilical cable with connectors comes with the controller.
Also included with the digital controller is a lockable steel wall mountable enclosure with a switch that controls the lift’s movements. A 30 foot-long extension with connectors is included and additional extensions are available separately.
Datasheet InstallationPDF Reader| SPECIFICATIONS | PACKAGE CONTENTS |
| Material: Steel Enclosure | 1pc – Digital Controller |
| Finish: Powder Coat | 1pc – Wall Switch Box |
| Color: Gray | 1pc – 6’ Umbilical Cable |
| Power: 230v 60Hz, 20 amps 3 phase | 1pc – 30’ Wall Switch Cable |
| Design Factor: 7:1 | 4pcs – Contact Switch Cables |
